The Fluke 2680A Data Acquisition System is the choice for multi-channel applications requiring reliable Ethernet communications. It features a front-end style data acquisition system that communicates and distributes data anywhere you need it to go. The 10BaseT and 100BaseT communications interface makes it compatible with both older and newer network installations.

Scale your system to meet your needs
With the Fluke 2680A and the , you can seamlessly expand your system from 20 to more than 2,000 channels just by adding modules and chassis. Both models feature six slots in each chassis that you can fill with modules as needed to meet your application requirements. Five slots in each chassis are available for any combination of 20-channel analog input modules. The sixth slot is also available for a digital I/O relay module to add control capabilities to your system. If you don’t need the sixth slot for control, you can plug in an additional analog input module, increasing your input channel count to 120 in one chassis.
You can also link multiple 120-channel systems together seamlessly for the widest possible view of your data. And, with TCP/IP connectivity, you can connect to existing LANs to distribute information wherever it needs to go.
Whether you need speed and throughput, isolated precision, or digital I/O and relays, the Fluke 2680 Series can scale up to thousands of channels to meet your needs. Buy just the modules you need in the combinations you need and expand your system as your requirements grow.

• 20 to 120 universal analog inputs per chassis; systems to +2,000 channels
• Stand-alone data logger operation with the 2686A
• Large scalable LAN systems using the 2680A with 10BaseT/100BaseT
• Two types of Universal Input Modules: high-isolation precision modules or fast scan modules, with 16- to 18-bit resolution
• Throughput of more than 3,000 channels-per-second-per-chassis with 2680A-FAI modules
• Superior thermocouple measurement accuracy (J, K, R, S, T, N, I, U, C, B)
• 20 digital I/O and 8 form C, 1 Amp relay output modules for direct control of equipment
• Up to 300V input isolation, 1600V transient overvoltage protection (2680A-PAI)
• Universal input conditioning for any input, on any channel, in any combination (V dc, V ac, Ohms, frequency, RTD, thermocouple, thermistor or current
• ATA flash memory card for stand-slone operation - from 16 MB to 1 GB (2686A only)
• Multiple power sources: 100 to 240 V and 9 V to 45 V dc
