The 1GC1-8213 is a DC10 GHz, 11dB gain, feedback amplifier designed to be used as a cascadable gain block for a variety of applications. The device consists of a modified Darlington feedback pair which reduces the sensitivity to process variations and provides 50 ohm input/output port matches. Furthermore, this amplifier is fabricated using Keysights Heterojunction Bipolar Transistor (HBT) process which provides excellent process uniformity, reliability and 1/f noise performance. The device requires a single positive supply voltage and generally operates ClassA for good distortion performance. DC power dissipation is less than 0.68 watts.

Please contact MMIC helpline: mmic_helpline@keysight.com for more details.

Packaged RF Via Power SMT

Frequency Range: DC-10 GHz

Moderate Gain: 11 dB

P -1dB: +19 dBm

Low 1/f Noise Corner: < 20 kHz

Return Loss: input 15 dB, Output: 10 dB

Single Supply Operation: V Supply > 4. 8 volts
