The CS1247-G Broadband Signal and Environment series provides the widest bandwidth and deepest memory RF/baseband signal generator available. The BSG combines broadband RF upconverters, wide bandwidth high dynamic range DACs and high speed memory with powerful DSP-based signal creation software. Real signals, including recording using Aeroflex’s Broadband Signal Analyzers or other recorder sources can be imported, combined with digitally generated signals, and then played back on the BSG for ultra-realistic test scenarios.Applications include:

Radar

Communications

EW/ECM

Spectrum monitoring

EME

Aeroflex’s Vector Signal Player (VSP) software provides simple controls for signal file selection, and output frequency and power control. Aeroflex’s up converters use real (non-I/Q) conversion architectures, generating high dynamic range waveforms without the carrier leakage and signal image problems associated with I/Q modulators found in traditional signal sources. The Vector Signal Simulator (VSS) software provides the unique ability to mix any combination of signals and impairments to generate complex signal environments.

EXPORT CONTROL: This product is controlled for export under the International Traffic in Arms Regulations (ITAR). A license from the U.S. Department of State is required prior to the export of this product from the United States.

RF Range : 2-6000 MHz
Full scale output power : -10 to -60 dBm
Instantaneous IF Bandwidth : 60 MHz or 400 MHz
Playback bandwidth : 400, 60, 42, 21, … MHz-41kHz; factors of 2
Signal RAM : 32 GB
Disk based onboard storage : 8TB RAID
Application Software : Data Creation and Control
GPS (Time and Location) : GPS Antenna or IRIG-B
Size : 5U (2U+3U) rack mount
Options : Analyzer Channel
