The industrys first Wound Component Electrical Safety Test (EST) Analyzer that combines impulse winding (surge testing), AC/DC hipot, insulation resistance and DC resistance test measurement functions. Chromas 19036 Wound Component EST Analyzer has 5KVac/6KVdc high voltage output, 5KV insulation resistance, 6KV layer short impulse (surge) voltage, and 4-wire DC resistance measurement with a maximum output of up to 40 channels. Capable of outputting and measuring AC 100mA/DC 20mA, Chromas 19036 is suitable for testing to high power motor standards like UL 1004-1. Its 500VA design is also compliant with the output power requirements of EC/UL standards. Wound component applications include EV motors, servomotors, ascension motors, transformers, solenoid valves, and stator surge testing.

AC/DC/IR 3 in 1 hipot tester
AC 5kV and DC 6kV output
1kV insulation resistance test
Insulation resistance measurement from 1M to 50
Ground continuity check
Open Short Check(OSC) function
GFI shutdown the instrument when imbalance current > 0.5mA
Flashover (ARC) detection
Quick discharge of DUT in IR and DC test
Pause mode
Large LCD display (240 × 64 dots matrix)
UL and TUV approved (*see spec)
CE mark
Programmable ramp/fall and test time
Programmable high/low limit
Save/Recall program test function
Remote control and interface support
2-Year factory warranty

Guardian 19052 Hipot Test (AC/DC/IR)
Guardian 19053 Hipot Test (AC/DC/IR/8CH SCAN)
Guardian 19054 Hipot Tester (AC/DC/IR/4CH SCAN)
