• Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
• Rugged urethane molded case protects the module from rough handling and harsh conditions
• Features internal temperature compensation from 0º C to 50º C for full-accuracy performance
• Includes NIST-traceable calibration certificate
• Module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source
• One year warranty

Range
 1 psi / 6900 Pa

Resolution
 0.0001 / 0.7

Reference Uncertainty (23 ± 3° C)
 0.150%

Total¹ Uncertainty 1 year
 0.300

High Side Media²
 Dry

Low Side Media²
 Dry

Note
1)     Total uncertainty, one year for temperature range 0° C + 50° C.
 Total uncertainty, 1.0% of full span for temperature range - 10° C to 0° C.
 Compensated temperature range is 15° C to 35° C.
2)     "Dry" indicates dry air or non-corrosive gas as compatible media.
 "316 SS" indicates media compatible with Type 316 Stainless Steel.
 "C276" indicates media compatible with Hastelloy C276.
