The R&S FS?K96PC OFDM analysis software extends the capability of the R&S FSQ/FSG/FSV/FSVR/FSW signal and spectrum analyzers and the R&S FSUP signal source analyzer to include modulation measurements on general OFDM signals. The OFDM demodulator is user-configurable and standard-independent.

Extension of the capability of the R&S FSQ/FSG/FSV/FSVR/FSW signal and spectrum analyzers and the R&S FSUP signal source analyzer to include transmitter measurements on general OFDM signals
User-definable and standard-independent OFDM demodulator
Wizard with a step-by-step guide for easy setup of the configuration file from a captured signal
Support of OFDM and OFDMA
Support of any PSK or QAM modulation format (up to 4096QAM)
Frequency range from 20 MHz to 3/8/26.5/40 GHz, depending on the analyzer model
Very low residual EVM < 51 dB for DVB-T, 2k mode (R&S FSQ)
RF measurement or optional I/Q baseband measurement
Generation of an ideal reference signal based on the configuration file

R&S FS?K96PC : OFDM Vector Signal Analysis Software
R&S FSPC : Licence Dongle
