The HMMC-5026 is a broadband GaAs MMIC traveling wave amplifier designed for moderate gain and moderate output power over the full 2-26 GHz frequency range. Typical applications of the HMMC-5026 include wideband gain blocks of communication systems and microwave instrumentation, which require a flat gains response and excellent port matches over the 2-26 GHz frequency range.Keysight HMMC-5026 does not contain any intentionally added RoHS substances above permitted maximum thresholds.All HMMC parts are manufactured in Santa Rosa, California using Keysights reliable instrument grade GaAs process.

Wide Frequency Range: 2-26.5 GHzModerate Gain: 9.5 dBGain Flatness: 0.75 dBReturn Loss: Input: -14 dB Output: -13 dBLow Frequency Operation Capability: < 2 GHzGain Control: 35 dB Dynamic RangeModerate Power: 20 GHz: P-1dB 18 dBm PSAT 20 dBm / 26.5 GHz: P-1dB 15 dBm PSAT 17 dBm
