The Chroma 11021/11021-L are the most cost-effective digital LCR Meters available, providing 100Hz, 120Hz, 1kHz, and 10kHz test frequencies for the 11021 and 1kHz, 10kHz, 40kHz, 50kHz test frequencies for the 11021-L. The standard RS232 interface, optional GPIB & Handler interfaces, high speed and stable measurement capabilities enable the Chroma 11021/11021-L for use inboth component evaluation on the production line and fundamental impedance testing for bench-top applications.

Test frequencies:
100Hz, 120Hz, 1kHz and 10kHz (9.6kHz) (11021)
1kHz, 10kHz, 40kHz, 50kHz (11021-L)
Basic accuracy: 0.1% (11021), 0.2% (11021-L)
0.1mO~99.99 MO measurement range, 4 1/2 digits resolution
Lower harmonic-distortion affection
Fast measurement speed (75ms)
Standard RS-232 interface
Optional GPIB & Handler interface
Programmable trigger delay time is convenient for measurement timing adjustment in automatic production
Bin-sorting function
Comparator and pass/fail alarming beeper function
Text mode 40×4 matrixes LCD display
Friendly user interface
Open/short zeroing
On-line fireware refreshable (via RS-232)
Input protection (1 Joule)

11021 LCR Meter 100-10kHz
11021-L LCR Meter 1k-50kHz
