The Model 237-ALG-2 is a 2m (6.6 ft) low noise triax cable (SC-22) terminated with a 3-slot male triax connector on one end and 3 alligator clips on the other. For use with: 237, 486, 487, Series 2200, Series 2600B, 4200-PA, 6220, 6221, 6487, 6514, 6482, 6517A, 6517B

Electrical characteristics
Working voltage: 600 V peak center conductor to inner shield; 1,300 V peak center conductor and inner shield to outer shell
Contact resistance: < 0.5 Ω
Insulation resistance: 1015 Ω, center conductor to inner shield (500 V test voltage, 23 °C at < 40 percent relative humidity)


General characteristics
Operating environment: 32 °F to 122 °F (0 °C to 50 °C), up to 70 percent relative humidity at ≤ 95 °F (35 °C)
