The MSO1000Z Series is the new economic level Digital Oscilloscope from Rigol to meet the customer’s applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The MSO1000Z 4 channel oscilloscopes come in 70 or 100 MHz versions with a 7 inch display and Rigol’s UltraVision technology and a 16 bit digital input port for mixed signal applications as well as a host of options. Add the optional analysis, decoding, deep memory, and integrated 2 channel waveform generator for a powerful 4 channel scope at an exceptional price.

100MHz Bandwidth, 4 analog channels
16 digital channels for Mixed Signal analysis
1G Sa/s Real-time Sample Rate
12Mpts (Std.) and 24Mpts (Opt.) Memory Depth
Innovative “UltraVision” technology
Up to 30,000wfms/s Waveform Capture Rate
7 Inch WVGA (800×480), multiple intensity levels waveform display

Bandwidth : 1 GHz
Analog Channels : 4
Vertical Sensitivity : 2 mV/div – 10V/div
Real-time Sample Rate : 5 GSa/s_single channel mode__2.5 GSa/s_dual channel mode_
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 180,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, , FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 1 GHz
Analog Channels : 2
Vertical Sensitivity : 2 mV/div – 10V/div
Real-time Sample Rate : 5 GSa/s_single channel mode2.5 GSa/s_dual channel mode
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 180,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, , FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 600 MHz
Analog Channels : 4
Vertical Sensitivity : 2 mV/div – 10V/div
Real-time Sample Rate : 5 GSa/s_single channel mode2.5 GSa/s_dual channel mode
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 180,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, , FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 600 MHz
Analog Channels : 2
Vertical Sensitivity : 2 mV/div – 10V/div
Real-time Sample Rate : 5 GSa/s_single channel mode2.5 GSa/s_dual channel mode
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 180,000 Waveforms per Second
Standard Interface : USB Host & Device VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Model : MSO4054
Analog Channels : 4
Digital Logic Channels : 16
Frequency : 500 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4052
Analog Channels : 2
Digital Logic Channels : 16
Frequency : 500 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4034
Analog Channels : 4
Digital Logic Channels : 16
Frequency : 350 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4032
Analog Channels : 2
Digital Logic Channels : 16
Frequency : 350 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4024
Analog Channels : 4
Digital Logic Channels : 16
Frequency : 200 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4022
Analog Channels : 2
Digital Logic Channels : 16
Frequency : 200 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4014
Analog Channels : 4
Digital Logic Channels : 16
Frequency : 100 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Model : MSO4012
Analog Channels : 2
Digital Logic Channels : 16
Frequency : 100 MHz
Memory Depth : 140 Million Points (analog); 28 Mpts (digital)
Waveform Acquisition Rate : 110,000 Waveforms per Second (analog); 85,000 Wfms/sec (digital)
Bandwidth : 500 MHz
Analog Channels : 4
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 500 MHz
Analog Channels : 2
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 350 MHz
Analog Channels : 4
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 350 MHz
Analog Channels : 2
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 200 MHz
Analog Channels : 4
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 200 MHz
Analog Channels : 2
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 100 MHz
Analog Channels : 4
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Bandwidth : 100 MHz
Analog Channels : 2
Vertical Sensitivity : 1 mV/div – 10V/div
Real-time Sample Rate : 4 GSa/s
Memory Depth : 140 Million Points
Waveform Acquisition Rate : 110,000 Waveforms per Second
Standard Interface : USB Host & Device, VGA, LXI, Trig Out, 10 MHz In/Out
Vertical Resolution : 8 bits
Math : _, _, _, FFT, customizable user defined
Cursor Measurements : Manual, Track and Auto Measure modes
Model : MSO2302A
Bandwidth : 300 MHz
Integrated 2 Channel Source : No
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2302A-S
Bandwidth : 300 MHz
Integrated 2 Channel Source : Yes
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2202A
Bandwidth : 200 MHz
Integrated 2 Channel Source : No
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2202A-S
Bandwidth : 200 MHz
Integrated 2 Channel Source : Yes
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2102A
Bandwidth : 100 MHz
Integrated 2 Channel Source : No
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2102A-S
Bandwidth : 100 MHz
Integrated 2 Channel Source : Yes
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2072A
Bandwidth : 70 MHz
Integrated 2 Channel Source : No
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO2072A-S
Bandwidth : 70 MHz
Integrated 2 Channel Source : Yes
Analog Channels : 2
Sample Rate : 2 GSa/s ; 1 GSa/s digital
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : DS2302A
Bandwidth : 300 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2302A-S
Bandwidth : 300 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2202A
Bandwidth : 200 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2202A-S
Bandwidth : 200 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2102A
Bandwidth : 100 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2102A-S
Bandwidth : 100 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2072A
Bandwidth : 70 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : DS2072A-S
Bandwidth : 70 MHz
Analog Channels : 2
Sample Rate : 2 GSa/s
Max Memory Depth : 14Mpts(standard) ,56Mpts(option)
Display : 8 inch LCD display
Standard Interface : USB Host & Device, RS-232, P/F Out
Impedance : High Impedance and 50 Ohm matching
Model : MSO1104Z-S
Bandwidth : 100 MHz
Analog Channels : 4
Sample Rate : 1GSa/s (Single-channel), 500MSa/s(Dual-channel), 250MSa/s(Fulll-channel)
Max Memory Depth : 12Mpts(standard) ,24Mpts(option)
Max. Waveform Capture rate : Up to 30,000 wfms/s
Real Time waveform Record and Replay : Up to 60, 000 Frames(Opt.)
Std. Probes : RP2200 150MHz BW Passive Probe:4 sets
Built in 2 Ch Source : Yes
16 Digital Channels for
Mixed Signal Analysis : Yes
Model : MSO1104Z
Bandwidth : 100 MHz
Analog Channels : 4
Sample Rate : 1GSa/s (Single-channel), 500MSa/s(Dual-channel), 250MSa/s(Fulll-channel)
Max Memory Depth : 12Mpts(standard) ,24Mpts(option)
Max. Waveform Capture rate : Up to 30,000 wfms/s
Real Time waveform Record and Replay : Up to 60, 000 Frames(Opt.)
Std. Probes : RP2200 150MHz BW Passive Probe:4 sets
Built in 2 Ch Source : No
16 Digital Channels for
Mixed Signal Analysis : Yes

Product Average Rating:

(0 reviews)
