FieldFox is equipped to handle routine maintenance, in-depth troubleshooting and anything in between. FieldFox delivers Keysight-quality measurements wherever you need to go. Add FieldFox to your kit, and carry precision with you.

The VNAs base function is a transmission/reflection analyzer (S11, S21), and it can be configured to include full 2-port S-parameters. FieldFox can be ordered with additional capabilities: cable and antenna analyzer, built-in power meter, vector voltmeter, variable DC source, built-in GPS receiver, and remote control using an iPad or iPhone.

The following accessories are included with every FieldFox: AC/DC adapter, battery, soft carrying case, LAN cable, Quick Reference Guide and Users Guide.

Applications

Satellite communications, microwave backhaul

Military communications, radar systems

Active and passive device test

Accuracy

Get precise measurements that agree with benchtop results

CalReady, QuickCal, and ECal provide accurate return loss, distance-to-fault and S-parameters

Full 2-port unknown thru calibration

Rugged

Dust-free design with no fans, no vents extends instrument reliability in harsh environments

Water-resistant withstands salty, humid environments

MIL-PRF-28800F Class 2 compliant

MIL-STD-810G, Method 511.5 Procedure I requirements for operation in explosive environments (type tested)

Vector network analyzer (VNA)

30 kHz to18 GHz

Directivity >32 dB, dynamic range 100 dB to 9 GHz, 90 dB to 18 GHz

Flat output power ( 1 dB) across whole frequency range, adjustable in 1 dB steps

Transmission/reflection (S21, S11), or full two-port (S21, S11, S12, S22)

Cable and antenna analyzer

30 kHz to18 GHz

Distance-to-fault, return loss, cable loss

Vector voltmeter (VVM), power and pulse measurements

VVM: 30 kHz to18 GHz, compare phase and electrical length

Average power, peak power, and pulse characterization with USB power sensors

Built-in power meter: 5 kHz to18 GHz

FieldFox instrument attributes

Remote control via iPad or iPhone

Standard 3-year warranty

Battery life: 3.5 hours weight: 3.0 kg or 6.6 lbs

Operating temperature: -10 to +55 C (14 to 131 F)
