The Chroma 16502 Milliohm Meter is Chromas newest digital Milliohm Meter. 0.001m~1.9999M wide measurement range. DC, Pulsed, and Dry-circuit test current driving modes enable the Chroma 16502 tobe properly used in DC resistance measurements for various inductive components (coil, choke, and transformer winding etc.), cable, metallic contact (connector, relay switch etc.), and conductive materials.

Basic accuracy : 0.05%
Pulsed test current output mode is used to reduce thermal EMFs affection on milliohm measurement
DC test current output mode is used to fasten measurement speed for inductive DUT
Dry-circuit test current output mode (limited Max. 20mV) is used to measure such contact resistances where the maximum open-circuit voltage must be limited to 50mV
Temperature correction (TC function) regardless of material or temperature
Useful temperature conversion function for motor/ coil evaluation
4 channels R scan with balance check function for fan motor (combined with A165017 option)
0.001m~1.9999M wide measurement range with 4_ digits resolution
Standard RS-232 interface
Optional GPIB & Handler interface
Bin-sorting function
Comparator and pass/fail alarming beeper function
Large LCD display (240 × 64 dot-matrix)
Friendly user interface

16502 Milliohmmeter
